Designed for a wide range of stereo applications, including field recording, video production and studio use
Affordable, high-quality stereo pickup in a single microphone
Compact, lightweight design is perfect for camera-mount use
Pair of cardioid elements in X-Y configuration provides the spatial impact and realism of a live sound field
Battery-free operation when used with recording devices that provide plug-in power at the mic input
Rugged construction; built to endure the rigors of field production
On/off switch for convenient operation
6′ (1.8 m) cable permanently attached to microphone
[14:38:25] visual designer_direttore creativo: ELEMENTS Fixed-charge back plate, permanently polarized condenser
POLAR PATTERN X/Y Stereo
FREQUENCY RESPONSE 100-17,000 Hz
OPEN CIRCUIT SENSITIVITY -50 dB (3.1 mV) re 1V at 1 Pa
IMPEDANCE 600 ohms
MAXIMUM INPUT SOUND LEVEL 119 dB SPL, 1 kHz at 1% T.H.D.
DYNAMIC RANGE (typical) 82 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO 57 dB, 1 kHz at 1 Pa
POWER REQUIREMENTS 2-10V DC plug-in power
BATTERY TYPE 1.5V LR44
BATTERY CURRENT / LIFE 0.6 mA / 200 hours typical
SWITCH On/off
WEIGHT 3.9 oz (111 g)
DIMENSIONS 4.59″ (116.5 mm) long,
0.83″ (21.0 mm) maximum body diameter
OUTPUT CONNECTOR 3.5 mm stereo mini plug on cable
CABLE Permanently attached 6′ (1.8 m) cable with 3.5 mm stereo plug at output end
ACCESSORIES FURNISHED AT8405a stand clamp for 5/8″-27 threaded stands; 5/8″-27 to 3/8″-16 threaded adapter; LR44 battery; windscreen; soft protective pouch
AUDIO-TECHNICA CASE STYLE S10
